Benvenuto allo schema di montaggio RAEE STATION di FASTAND
![schema-montaggio-unieuro](https://www.fastand.it/wp-content/uploads/2023/08/schema-montaggio-unieuro-scaled.jpg)
Benvenuto nella sezione dedicata al montaggio della nuova Raee Station. Segui passo passo le istruzioni. Non necessita di utensili.
![IMG_0047](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0047.jpeg)
Aprire la scatola, attenzione a non affondare la lama per non rovinare gli elementi all’interno.
![11](https://www.fastand.it/wp-content/uploads/2023/08/11.jpg)
Lo sportello retro ha etichetta con QR code applicato, scansionalo per tornare a questa sezione
![IMG_0049](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0049.jpg)
Posizionare a terra la base della Raee Station. Togliere i ganci come da fotografica
![9](https://www.fastand.it/wp-content/uploads/2023/08/9.jpg)
Svitare i fissaggi, già inseriti nel foro pannello. Sono 4 superiori e 4 inferiori
![8](https://www.fastand.it/wp-content/uploads/2023/08/8.jpg)
Inserire i punti di fissaggio fra struttura e pannello grafico, 4 punti inferiori e 4 superiori
![7](https://www.fastand.it/wp-content/uploads/2023/08/7.jpg)
Attenzione: montare come da foto, con struttura visibile esterna e pannello interno
![2](https://www.fastand.it/wp-content/uploads/2023/08/2.jpg)
Contromensola: togliere le viti
![1](https://www.fastand.it/wp-content/uploads/2023/08/1.jpg)
Rifissare le viti, fra controsportello e sportello
![IMG_0052](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0052.jpg)
Fissare piano superiore
![f1566102-dc8e-4e4f-ac69-a6f4904e3699](https://www.fastand.it/wp-content/uploads/2023/08/f1566102-dc8e-4e4f-ac69-a6f4904e3699-e1693566609330.jpg)
Ci siamo quasi, adesso il crowner
![6](https://www.fastand.it/wp-content/uploads/2023/08/6.jpg)
Prendere il crowner
![IMG_0057](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0057.jpg)
Togliere le viti preinserite
![5](https://www.fastand.it/wp-content/uploads/2023/08/5.jpg)
Fissare nei 2 fori del piano
![IMG_0060](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0060.jpg)
Montaggio contenitori interni
![IMG_0061](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0061.jpg)
Segui i passaggi
![IMG_0062](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0062.jpg)
Segui i passaggi
![IMG_0063](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0063.jpg)
Segui i passaggi
![IMG_0064](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0064.jpg)
Segui i passaggi
![IMG_0065](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0065.jpg)
Segui i passaggi
![IMG_0067](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0067.jpg)
1 grande e 2 piccoli
![IMG_0068](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0068.jpg)
inserire contenitore con lato finestra rivolta verso oblò
![IMG_0069](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0069.jpg)
inserire contenitore con lato finestra rivolta verso oblò
![IMG_0071](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0071.jpg)
Anta apribile e chiusura
![5](https://www.fastand.it/wp-content/uploads/2023/08/5.jpg)
Svitare il pomolo nero preinserito
![IMG_0073](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0073.jpg)
prendere anta di chiusura retro
![4](https://www.fastand.it/wp-content/uploads/2023/08/4.jpg)
inserire anta nei 2 incastri inferiori
![IMG_0075](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0075.jpg)
L’ anta fa perno nei 2 incastri
![3](https://www.fastand.it/wp-content/uploads/2023/08/3.jpg)
Chiudere l’anta con il pomolo nero
![IMG_0079](https://www.fastand.it/wp-content/uploads/2023/08/IMG_0079.jpg)
Grazie per aver allestito una nuova raee station di Fastand.
Per una corretta pulizia si prega di utilizzare solo detergenti classici e carta, le superfici non temono l’umidità.
Buon lavoro.
